| Total thickness (mm) | Copper thickness (mm) | Width (mm) | Length (mm) |
| 0.6 | 2×0.02 | Less than 600 | 300-3000 |
| 1.0 | 2×0.05 | ||
| 2.0 | 2×0.10 | ||
| 3.0 | 2×0.15 |
| Material | Composition % | Density (g/cm3) | Electrical conductivity (m/Ω•mm2) | Tensile strength(Mpa) | Elongation(%) | Composite strength | ||
| Annealing state | Semi-hard state | Annealed state | Semi-hard state | |||||
| Copper clad steel | 5/90/5 | 7.9 | 12.7 | ≥265 | ≥365 | ≥37 | ≥15 | Without stratification after repeated bending test |
| Copper clad steel | 10/80/10 | 8.0 | 17.8 | ≥250 | ≥350 | ≥40 | ≥20 | |
| Brass clad steel | 5/90/5 | 7.9 | 8.5 | ≥270 | ≥370 | ≥35 | ≥15 | |
| Brass clad steel | 10/80/10 | 7.9 | 9.3 | ≥265 | ≥365 | ≥37 | ≥17 | |
| Bronze clad steel | 5/90/5 | 7.9 | 7.8 | ≥270 | ≥370 | ≥35 | ≥15 | |
