| Total Thickness(mm) | Copper thickness (mm) | Width(mm) | Length(mm) |
| 0.6 | 2*0.02 | Less than 600 | 300-3000 |
| 1.0 | 2*0.05 | ||
| 2.0 | 2*0.10 | ||
| 3.0 | 2*0.15 |
| Material | Composition | Density | Conductivity | Tensile Strength | Elongation | Composite Strength | ||
| Annealing State | Half hard State | Annealing Soft State | Half hard State | |||||
| Copper clad steel | 5/90/5 | 7.9 | 12.7 | >=265 | >=365 | >=37 | >=15 | Without stratification after repeated bending test |
| Copper clad steel | 10/80/10 | 8.0 | 17.8 | >=250 | >=350 | >=40 | >=20 | |
| Brass clad steel | 5/90/5 | 7.9 | 8.5 | >=270 | >=370 | >=35 | >=15 | |
| Brass clad steel | 10/80/10 | 7.9 | 9.3 | >=265 | >=365 | >=37 | >=17 | |
| Bronze clad steel | 5/90/5 | 7.9 | 7.8 | >=270 | >=370 | >=35 | >=15 | |
